CAC7-5 Air Compressor

The CAC7-5 is an ideal air compressor for blasting with our compact dry ice blasting machines. The compressor allows you to blast with compressed air which is needed to keep the dry ice solid and maintain the good quality of the ice.

  • Integrated with an after cooler
  • Special re-heater for dry ice blasting
  • Ultra fine filters for compressed air quality according to German standard ZTV-ING Teil 3, Abs. 4

Suited for COB62 Dry Ice Blaster.

ADD TO YOUR DRY ICE QUOTE

Features

Technical Data

Downloads

  • Stable regulation with large speed range, reduces fuel consumption
  • Discharged starting of the engine soft start with compressor off load
  • Bolted individual panels with detachable insulating mats low-cost and quick replacement
  • Robust plastic protection protects the lighting elements
  • Hot-galvanised trailer chassis including individual adoption long- life and versatile
  • Large fuel filter with water separator and manual filling pump

Article number:  P25060
Operation pressure (bar):  7
Volume flow (m³/min):  5.5
Cooling system:  Water
Installed engine power (kW):  42
Speed at full capacity(rpm):  2700
Fuel tank capacity (l):  60
Sound power level (db(A))-Acc. to 2000/14/EC:  98
Sound pressure level (db(A))-Acc. to ISO 3744 (r:10):  69
Weight:  740kg
Length:  2980 – 3420mm
Width:
1540mm
Height:
  1370mm
